Norsat WAYFARER 1.2m Ku-Band Manual Flyaway Antenna
The Norsat WAYFARER™ commercial 1.2m fly-away antenna is a fast deploying, easy-to-use, and compact SATCOM VSAT. This terminal is an excellent choice for commercial applications in various industries.
fly-away antenna offers excellent rugged and reliable satellite links. Ideally suited for remote enterprise, energy, emergency, and media applications.
| WFM120KU Key Specifications | |
|---|---|
| Acquisition And Tracking | Manual |
| Band | Ku-Band |
| Product Family | WFM120KU |
| Receive Frequency | Ku Band: 10.70 - 12.75 GHz |
| Reflector Diameter | 1.2 m |
| Transmit Frequency | Ku-Band: 13.75 - 14.50 GHz |
| Antenna Specifications |
|
| Azimuth Range | +/- 200° |
| Cross Polarization Isolation | ≥35 dB |
| Elevation Range | 0 - 90° |
| Feed Configuration | Centre-feed |
| Polarization | Linear +/- 90° |
| Standard Buc Options | 2W,3W,4W,6W,8W,10W,16W,20W,40W |
| Standard Lnb Options | 1000H or HS1000 |
| RF Specifications |
|
| Movement Platform | Elevation over Azimuth |
| Rx Gain | 41.5+20log(f/12.5) dBi |
| Tx Gain | 42.5+20log(f/14.25) dBi |
| Interface Specifications | |
| Interfacility Link Cable | 10 m |
| Environmental Specifications |
|
| Humidity | 0 - 95% (20°C) |
| Temperature Operational | -40°C to +60°C (Antenna) |
| Weatherproofing | IP 65 (antenna only) |
| Windspeed Operational | 36 km/h |
| Windspeed Survival | 65 km/h |
| Physical Specifications | |
| Number Of Cases | 2 standard |
