Norsat WAYFARER 0.8m Ka-Band Manual Flyaway Antenna
The Norsat WAYFARER™ commercial 0.8m fly-away antenna is a fast deploying, easy-to-use, and compact SATCOM VSAT. This terminal is an excellent choice for commercial applications in various industries.
fly-away antenna offers excellent rugged and reliable satellite links. Ideally suited for remote enterprise, energy, emergency, and media applications.
| WFM080KA Key Specifications | |
|---|---|
| Acquisition And Tracking | Manual |
| Band | Ka-Band |
| Product Family | WFM080KA |
| Receive Frequency | Ka-Band: 19.2 to 20.2 GHz |
| Reflector Diameter | 0.8m |
| Transmit Frequency | Ka-Band: 29.0 to 30.0 GHz |
| Antenna Specifications |
|
| Azimuth Range | ±180° |
| Cross Polarization Isolation | ≥35 dB |
| Elevation Range | 0 - 90° |
| Feed Configuration | Centre-feed |
| Polarization | Circular +/- 90° |
| Standard Buc Options | 12W,15W,50W |
| Standard Lnb Options | 9000 Series |
| RF Specifications |
|
| Movement Platform | Elevation over Azimuth |
| Rx Gain | 41.4 + 20lg(f/20.0) dBi |
| Tx Gain | 45.0 + 20lg(f/30.0) dBi |
| Interface Specifications | |
| Interfacility Link Cable | 10 m |
| Environmental Specifications |
|
| Humidity | 0 - 95% (20°C) |
| Temperature Operational | -40°C to +60°C (Antenna) |
| Weatherproofing | IP 65 (antenna only) |
| Windspeed Operational | 70 km/h |
| Windspeed Survival | 100 km/h |
| Physical Specifications | |
| Number Of Cases | 1 standard |
