Norsat SL180KU SigmaLink 1.8m Ku-Band Auto-Acquire Flyaway Antenna
Norsat SL180KU SigmaLink 1.8m Ku-Band Auto-Acquire Flyaway Antenna
Sale
Sold out
Couldn't load pickup availability
Norsat SigmaLink 1.8m Ku-Band Auto-Acquire Flyaway Antenna
The new Norsat SigmaLink™ AUTO is the latest in a series of transportable satellite terminals. The SigmaLink™ is ideally suited to provide broadband connectivity for base camps or other prolonged missions where assignments are temporary but deployment is protracted. With simple setup and automatic acquisition, personnel with minimal training can have the SigmaLink™ AUTO up and transmitting in minutes.
| SL180KU Key Specifications | |
|---|---|
| Acquisition And Tracking | Automatic |
| Band | Ku-Band |
| Product Family | SL180KU |
| Receive Frequency | Ku-Band: 10.95 - 12.75 GHz |
| Reflector Diameter | 1.8 m |
| Transmit Frequency | Ku-Band: 13.75 - 14.50 GHz |
| Antenna Specifications |
|
| Axial Ratio | n/a |
| Azimuth Range | +/- 35° fine adjust |
| Cross Polarization Isolation | -85 dB (Tx - Rx); -30 dB (Rx - Tx) |
| Elevation Range | 5° - 90° |
| Feed Configuration | 2-port circular |
| Polarization | +/- 90° |
| Primary Antenna Power | 115 / 230 VAC (50 / 60 Hz) |
| Standard Buc Options | 20W, 40W, 80W |
| RF Specifications |
|
| Eirp | 58.3 dBW (Tx) |
| G T | 23.7 dB/K (Rx) |
| Input VSWR | 2.2 : 1 |
| Midband Gain | 46.8 dBi (TX); 45.1 dBi (RX) |
| Output Vswr | 2.2 : 1 |
| Reference Signal Frequency | 0 +/- 5 dBm @ 10 MHz |
| Rx Gain | 65 dBm |
| Spectral Regrowth | -26 dBc @ 44 dBm |
| Tx Gain | 50 dBi |
| Environmental Specifications |
|
| Humidity | 0 - 100% condensing (Antenna / RF); 5 - 95% non-condensing (Indoor Equipment) |
| Rainfall Survival | 100 mm/h |
| Temperature Operational | -30°C to +50°C (Antenna/RF) ; 0 to 50°C (Indoor Equipment) |
| Windspeed Operational | 72 mm/h |
| Windspeed Survival | 108 mm/h |
| Interface Specifications | |
| Interfacility Link Cable | 10 m (Standard); 30 m (Optional) |
