Norsat GLOBETrekker 1.2 m Ku-Band Auto Acquire Flyaway Antenna
The GLOBETrekker™ 2.0 is the world’s most intelligent fly-away satellite terminal. With a modular architecture that enables easy component swapping in the field, a simple one touch interface, and intelligent LinkControl™ software for automatic satellite acquisition, the GLOBETrekker is both powerful and easy to use. Built to military specifications, with a suite of integrated modems or video encoders, and lightweight packaging compact enough for airline check in, operators rely on the GLOBETrekker for mission critical communications anywhere on the planet.
| GT120KUE040 Key Specifications | |
|---|---|
| Acquisition And Tracking | Automatic |
| Band | Ku-Band |
| Lo Stability | +/- 5 kHz or external reference |
| Product Family | GT120KUE040 |
| Receive Frequency | Ku-Band: 10.95 - 12.75 GHz |
| Reflector Diameter | 1.2 m |
| Transmit Frequency | Ku-Band: 13.75 - 14.50 GHz |
| Antenna Specifications |
|
| Axial Ratio | n/a |
| Azimuth Range | > +/- 100°, Motorized (resolution <0.1°) |
| Cross Polarization Isolation | 30 dB on axis |
| Elevation Range | 5° to 90°, Motorized (resolution <0.1°) |
| Feed Configuration | 2-port circular |
| Movement Overrides | Manual (Azimuth/Elevation/Polarization) |
| Polarization | Linear Cross-Pol |
| Primary Antenna Power | 24V DC; AC 110/220 VAC; 50/60 Hz (Stable to 90 VAC) |
| Standard Buc Options | 4W, 8W, 16W, 20W, 35W, 40W, 80W |
| RF Specifications |
|
| Eirp | 57.6 dBW |
| G T | 20.2 dB/K |
| Max Ssg Variation | +/- 1 dB per 54 MHz |
| Movement Platform | Motorized Elevation over Azimuth |
| Reference Signal Frequency | 0 +/- 5 dBm @ 10 MHz |
| Rx Gain | >41 dBi (mid band) |
| Spectral Regrowth | -26 dBc |
| Tx Gain | >43 dBi (mid band) |
| Environmental Specifications |
|
| Humidity | 5-95 % condensing, meets MIL-STD-810G |
| Rainfall Survival | 360 mm/h, meets MIL-STD-810G |
| Salt Mist | Meets MIL-STD-810G |
| Shock | Meets MIL-STD-810G |
| Temperature Operational | -30°C to +55 °C, meets MIL-STD-810G |
| Temperature Storage | -40 to +70˚C |
| Temperature Survival | -40 to +70°C, meets MIL-STD-810G |
| Vibration Loose Cargo | Meets MIL-STD-810G |
| Vibration Operational | Meets MIL-STD-810G |
| Vibration Random | Meets MIL-STD-810G |
| Weatherproofing | Meets MIL-STD-810G |
| Windspeed Operational | 50 km/h, meets MIL-STD-810G |
| Windspeed Survival | 100 km/h, meets MIL-STD-810G |
| Physical Specifications |
|
| Iata Cases Available | Optional |
| Number Of Cases | 3 standard, 4 IATA |
