Norsat 8530I Series DRO C-Band (4.5 to 4.8 GHz) Digital LNB

Norsat 8530I Series DRO C-Band (4.5 to 4.8 GHz) Digital LNB

Request for a quote

SKU: NOR-8530I

Norsat 8530I Series DRO C-Band (4.5 to 4.8 GHz) Digital LNB

The Norsat 8530I has reached end of life and has been replaced by the Norsat 5250RF.  Please contact Digisat for more information.

The Norsat 8530i Series C-Band DRO LNB has a local oscillator frequency of 5.95 GHz and operates from 4.50 to 4.80 GHz. The 8530i LNB features a groundbreaking 30 K noise temperature rating. This DRO Norsat C-Band LNB has a CPR229 waveguide input and offers outstanding Local Oscillator (L.O.) stability of ±500 kHz.  F connector or Type-N Output.

FREQUENCY BANDS AVAILABLE
Typical service 8000I
Input frequency (GHz) 4.50 to 4.80
L.O. frequency (GHz) 5.95
Output frequency (MHz) 1150 to 1450


TYPICAL SPECIFICATIONS
Noise temperature 30K
L.O. stability (over temperature excl offset) ±500 kHz
Phase noise (SSB) ▼
1kHz -65 dBc/Hz
10kHz -80 dBc/Hz
100kHz -95 dBc/Hz
Input VSWR 2.0 : 1
Output VSWR 2.2 : 1
Conversion gain 64 dB
Output P1dB 8 dBm
Power requirements +15 to +24 V supplied through center conductor of IF cable
Current drain 130 mA
Input Waveguide CPR 229G
Dimensions 180 (L) x 100 (W) x 70 (H) mm
(7.1 x 4.0 x 2.8 in)
Weight 425 g / 15 oz
Temperature Range -40°C to +60°C
