Norsat 3230 Series High Stability C-BAND PLL LNB ±10 kHz

Norsat 3230 Series High Stability C-BAND PLL LNB ±10 kHz

Input Type
Request for a quote

SKU: NOR-3230F

Norsat 3230 Series High Stability C-BAND PLL LNB ±10 kHz

Norsat Satellite Communication solutions are renowned for their high quality, reliability, and innovation. Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communication around the world.  Norsat LNBs feature:

  • - The industry’s best LO (Local Oscillator) stability
  • - High performance for any application
  • - Excellent availability and short lead times Stock units are available in standard and extended C-Band frequencies. Special order units are available in a wide variety of additional frequencies from 10.38 – 10.55 GHz up to 17.7 - 18.1 GHz.

Norsat 3230 Series High Stability C-BAND PLL LNB ±10 kHz

FREQUENCY BANDS AVAILABLE

Input frequency (GHz) 3.40 to 4.20
L.O. frequency (GHz) 5.15
Output frequency (MHz) 950 to 1750


TYPICAL SPECIFICATIONS

Noise temperature 30K
L.O. stability (over temperature excl offset) ±10 kHz
Phase noise (SSB)
1kHz -80 dBc/Hz
10kHz -85 dBc/Hz
100kHz -95 dBc/Hz
Input VSWR 2.2 : 1
Output VSWR 2.2 : 1
Conversion gain 62 dB
Output P1dB 9 dBm
Power requirements +12 to +24 V supplied through center conductor of IF cable
Current drain 250 mA
Input Waveguide CPR229G
Dimensions 144 (L) x 70 (W) x 98 (H) mm
(5.7 x 2.8 x 3.9 in)
Weight 500 g / 17.6 oz
Temperature Range -40°C to +60°C
Relative Humidity 0 - 100% condensing
