iDirect/ST Engineering MDM5010 Satellite Modem

iDirect/ST Engineering MDM5010 Satellite Modem

Request for a quote

The MDM5010 Satellite Modem is a high throughput modem supporting a wide range of fixed IP services, including enterprise, cellular backhaul and maritime connectivity as well as multicasting. The modem features high throughput DVB-S2X and Dialog’s award winning Mx-DMA return waveform technology as well as DVB-S2X with SCPC returns.

The MDM5010 Satellite Modem is a very high throughput modem capable of handling traffic up to 1.2 Gbps in a shared bandwidth mode. With Mx-DMA service providers can now cover a myriad of use cases in a single return link from vessels and large enterprise customers to cellular backhaul connectivity and broadcasting services, all while achieving the lowest total cost of ownership (TCO). The high spectral efficiency, high packet and bit rate capability makes the MDM5010 ideal for the most demanding customers with very bandwidth-intensive services. Service Providers can have a business model with maximum flexibility in supported applications, responsiveness to new market opportunities and Service Level Agreement (SLA) schemes that fit customers’ needs.

The modem’s ease of installation through multilingual web GUIs and Point&Play application allows services providers to deploy their services quickly, in a cost-effective way.

Coming soon: The All-New MDM5010 Satellite Modem, our fastest VSAT modem with award winning Mx-DMA technology, now also features the industry’s fastest SCPC Point-to-Point technology with speeds of 1.6Gbps.

Features of the MDM5010

  • DVB-S2 (up to 64 Msps) / DVB-S2X (up to 500 Msps) outbound

  • Supports a full range of DVB-S2X MODCODS up to 256APSK

  • Return max rates up to 133 Msps (DVB-S2X/SCPC), 68 Msps (MxDMA)

  • Supports 220Msps (SCPC P2P)

  • OpenAMIP and GXT file support

  • Embedded TCP acceleration, GTP acceleration and header compression

Network Configuration

Network Topology

Rx

 Tx
VSAT mode DVB-S2/DVB-S2X MF-TDMA Mx-DMA Mx-DMA MRC SCPC
Modulation QPSK, 8PSK, 16APSK, 32APSK,
64APSK, 128APSK, 256APSK		 4CPM 16APSK, 32APSK 32APSK, 64APSK 32APSK, 64APSK
Symbol Rates 1 Msps to 500 Msps Up to 7.6 Msps 32 ksps to 68 Msps up to 25 Msps 1 Msps to 133 Msps
SCPC P2P mode** SCPC SCPC
Modulation QPSK, 8PSK, 16APSK, 32APSK
64APSK, 128APSK, 256APSK		 QPSK, 8PSK, 16APSK, 32APSK,
64APSK, 128APSK, 256APSK
Symbol Rates 1 Msps to 220 Msps 1 Msps to 220 Msps

Modem Interfaces

Tx Interface

Connector N-Type 50 Ohm
Frequency range  L-band 950-2400 MHz
TX level  -55 dBm to +5 dBm
BUC power supply none
BUC reference 10/50 MHz (BNC)


Rx Interface

Frequency 950-2150 MHz
Connector N-Type 50 Ohm*
LNB power supply 13/18VDC, 500mA
LNB LO selection 22 kHz on/of
LNB reference 10 MHz
Dual Tx/Rx ports**

Data Interface

LAN: Six 10/100/1000 Mbps Ethernet, auto MDI/MDIX Two optical Ethernet interfaces (SFP)**

Management Interface
Four 10/100/1000 Mbps Ethernet, auto MDI/MDIX

Future Use
 USB USB 2.0
MicroSD card Mass storage option

*Optional external B type to F type lossless converters are orderable
** Feature available end of Q3 2021, MDM5010 (HW-02)
Specifications subject to change without notice

Management

Protocols Supported

Terminal Authentication, UDP, IP, IPv6, ICMP, TCP, ARP, FTP, DHCP, BGP, NAT, IP forwarding, Diffserv, DNS, IGMPv1/2,

Multilingual Web GUI

Manage web GUI via configurable management IP address

Mechanical and Environmental

Housing Height: 1RU, width: 19”, depth 44.5 cm (17.52 in)
Weight 8.0 kg (17.637 lbs)
Temperature:
Operating 0° to +50°C (32° to +122°F)
Storage -10° to +60°C (14° to +140°F)
Humidity
Operating  5 - 95% non-condensing

Power Supply

Input Voltage AC, 50Hz\220-260 V, 60Hz\100-130 V
36-76VDC or -48VDC (hardware option)
